Product specification and description
ASTM A106 seamless pressure pipes (also known as ASME SA106 pipes) are commonly used in the construction of oil and gas refineries, power plants, petrochemical plants, boilers and ships. These pipes must carry fluids that exhibit higher temperature and pressure levels And gas.
ASTM A106 Gr.B is an American brand, and A106 Gr.B has no corresponding brand in China. The chemical composition of A 106Gr.B is as follows:
1. C≤0.25
2. Mn=0.27-0.93
3. P≤0.035
4. S≤0.035
5. Si≤0.1
6. Cr≤0.4
7. Cu≤0.4
8. Mechanical properties: ób≥415／MPa , ós≥240／MPa.
The chemical composition of the material does not correspond to Chinese materials, and the mechanical properties are similar to Chinese (GB/T699) 20# steel. ASTM is a set of American steel pipe standards. ASTM steel pipe A106 A corresponds to the Chinese standard is GB8163 and the material is 10# steel. A106 B corresponds to the Chinese standard. The GB8163 material is 20#, and A106 Gr.B does not correspond to Chinese materials.
Our inspection of steel pipes generally includes: inspection of geometric size and surface quality: inspection of chemical composition, mechanical properties, technological properties, inspection of high-low tissue: non-destructive testing: inspection of some special properties and length measurement and weighing.
(1) Check the geometric size of the steel pipe
The outer diameter, wall thickness, bending degree and length of the steel pipe are checked on the inspection table with external calipers, micrometers, bending degree and length winding.
Sometimes, the outer diameter, wall thickness and length are also continuously tested by automatic size detection devices (such as automatic diameter measurement, thickness measurement, length measurement devices). For OCTG steel pipe also need to check the thread parameters.
(2) Check the inner and outer surfaces of the steel pipe
We generally use visual inspection for internal and external surface inspection, and in addition to visual inspection, the internal surface is also inspected by reflection prism. Some special purpose steel pipes also require non-destructive testing, including eddy current, magnetic leakage, ultrasonic, magnetic particle testing, etc., to check the quality of the inner and outer surface of the steel pipe.
(3) Mechanical properties and process performance inspection
In order to verify that the mechanical properties of the steel pipe meet the requirements of the standard, we need to conduct mechanical properties inspection on the steel pipe sampling.
The test of mechanical properties mainly includes tensile strength, yield strength, elongation, impact work, etc. The process performance test mainly includes flattening test, flaring test, water pressure test, flange test, cold bending test, perforating test and so on. These inspection items are selected according to the different standards and the difference in the use of the steel pipe.
(4) Non-destructive inspection
Our non-destructive testing methods include: magnetic leakage testing, ultrasonic testing, eddy current and fluorescent magnetic particle testing, ultrasonic spectrum analysis testing, ultrasonic imaging testing and ultrasonic high temperature testing
Material introduction
Carbon steel is a steel with carbon content from about 0.05 up to 2.1 percent by weight. The definition of carbon steel from the American Iron and Steel Institute (AISI) states:
no minimum content is specified or required for chromium, cobalt, molybdenum, nickel, niobium, titanium, tungsten, vanadium, zirconium, or any other element to be added to obtain a desired alloying effect;
the specified minimum for copper does not exceed 0.40%;
or the maximum content specified for any of the following elements does not exceed the percentages noted: manganese 1.65%; silicon 0.60%; copper 0.60%.
The term carbon steel may also be used in reference to steel which is not stainless steel; in this use carbon steel may include alloy steels. High carbon steel has many different uses such as milling machines, cutting tools (such as chisels) and high strength wires. These applications require a much finer microstructure, which improves the toughness.
Carbon steel is a popular metal choice for knife-making due to its high amount of carbon, giving the blade more edge retention. To make the most out of this type of steel it is very important to heat treat it properly. If not, the knife may end up being brittle, or too soft to hold an edge.
As the carbon percentage content rises, steel has the ability to become harder and stronger through heat treating; however, it becomes less ductile. Regardless of the heat treatment, a higher carbon content reduces weldability. In carbon steels, the higher carbon content lowers the melting point.
Warehouse display
We have a large steel product warehouse with a large inventory covering a wide range of specifications and types of products. Whatever specifications you need, we can provide them quickly, ensuring that your project is not affected by material shortages. Our product inventory is updated in real time, with new products coming into stock every day. This means that even in the case of high demand, we can guarantee a stable supply and avoid the risk of running out of stock. Our warehouse facilities are complete, with a sound storage and logistics system. This allows us to quickly complete the product entry, storage and exit work, ensuring that your ordered products can be delivered in a timely manner.
Product application
Each batch of our products will be subjected to strict quality testing before leaving the warehouse, we can also accept your designated third party testing agency for quality inspection and quality certificate, to ensure that all products do not have quality problems and can be perfectly applied to various fields.
Customer visit
Customer's visit is an important part of our long-term cooperative relationship, every customer's visit is our driving force forward, we value every communication with you. We are very welcome and look forward to your frequent visit, with us to explore more cooperation opportunities, we are committed to provide you with one-stop service, whether it is product consultation, technical support or business negotiations, we will go all out, in order to ensure that your visit is smooth, we have prepared all the necessary support and service, ready to meet your arrival.
Recommended product
In order to ensure the supply of sufficient goods for customers at all times, in addition to independent production of goods, we also maintain close cooperation with major manufacturers at home and abroad, if we do need to order their goods, then we will carry out strict quality testing of this batch of goods to ensure that there is no problem before delivery to customers.
FAQ
Are you trading company or manufacturer ?
We are specialized in the production and processing of various steel products suppliers, have their own independent plant and production equipment
Do you provide samples ? Is it free or extra ?
We can provide samples to you for free, but the cost of express delivery will be borne by you.
Do you support customization ?
Yes, we have a full stock of products with a full range of models and a working production line. If you don't have what you want, we can customize it.
How long is your delivery time?
It takes around 3-5 days for the regular models, and 7 to 10 working days for the special sizes and processing. It is based on the order quantity and requirement.
Do you accept third party testing ?
Yes, we fully accept the quality inspection of the third party inspection institutions. We attach great importance to the reliability of product quality
What are the advantages of your company?
First of all, we have an absolute advantage in price. Secondly, the quality of products is also strictly controlled.
